Increase speeds in electronic assembly systems

Motors & Drives


Design engineers looking to increase speeds in electronic assembly systems will find ServoClass couplings from Zero-Max a viable design option. These couplings povide high torsional stiffness, zero backlash and low hysteresis to ensure repeatable precise positioning at up to 10,000 rpm. The robust design ensures precise system operation in automated 24/7 applications, particularly true where stresses occur at increased speeds in a servo system. Designed with 304 stainless steel disc packs and 7075-T6 aluminum hubs, the couplings are inherently strong, durable and precisely balanced. To ensure precise alignment of the assembled components, ISO 4762 cl12.9 corrosion resistant socket head cap screws are utilized with a carefully controlled assembly process. In addition to electronic assembly systems, the couplings are ideal for all types of automation, packaging and other types of automated assembly including most systems using ball screws and servo motors. They are available in single and double flex models in inch and metric bore sizes from 0.157” (4mm) to 1.750” (45mm). all models and sizes feature clamp style hubs and operate in temperatures from -30 to 100°C.

Posted on November 15, 2011 - (1499 views)
