Clip-on Inspection Tool for BtoB Connector

Clip-on Inspection Tool for BtoB Connector

"BtoB Clip" is an inspection tool that can be quickly and easily connected to the Board to Board connector.

The Board-to-Board connector has a strong locking function.

However, there are disadvantages that it is difficult to inspect repeatedly attaching / detaching.

This problem is solved for "BtoB Clip".

"BtoB Clip" is an inspection tool that can be connected simply by inserting a BtoB connector into a guide part and clipping it.

A typical product to be inspected with "Clip Connector" is a liquid crystal display, but it is used for various products.

Please utilize our products to improve the inspection process of your products.

Read more
Discover More About Bonfiglioli's New Frequency Inverter with Higher Protection Rating and Performance

Discover More About Bonfiglioli's New Frequency Inverter with Higher Protection Rating and Performance

Bonfiglioli's well-proven S2U inverters are now also available at higher power and with an IP66 protection rating. The compact S2U IP66 Plug & Play inverter for single-phased 230-volt networks and three-phased 400-volt networks comes in three sizes with engine power ranging from 0.4 kW to 18.5 kW. The new S2U IP66 inverter series is particularly suited to applications that require high resistance to environmental impacts, as well as those that require high braking power without braking resistor, and a high torque at low speed such as packaging machines, textile machines, material handling, woodworking machines, pumps, fans, and many more. The heat sink was designed specifically for extreme environmental conditions such as dust, humidity, and cleaning chemicals. Due to the high protection rating, the robust and highly cost and energy-efficient inverters remain completely unaffected by even the most adverse of conditions.

Read more
High-resolution IR Camera With Microscope Optics

High-resolution IR Camera With Microscope Optics

Optris is expanding its range of non-contact temperature measurement sensors with compact, high-resolution infrared cameras with microscope lenses. As well as shots of the entire circuit board, detailed macro shots of individual components are possible and can be measured reliably. The macro shots are possible with a spatial resolution of 28 µm. The infrared cameras with microscope lenses come in a set with a high-quality table mount which allows for the simple fine-adjustment of the camera's focus, especially in the test & measurement range. The distance between the measurement object and the camera can vary between 80 and 100 mm. This flexible positioning of the measurement device allows for a simultaneous electric functional test without difficulty. With the license-free software both radiometric images and radiometric videos can be recorded at up to 125 Hz.

Read more
Ultrasonic Flow Meter for Low Flow Rates

Ultrasonic Flow Meter for Low Flow Rates

With the development of the ES-FLOW™ Flow Meter featuring a new Ultrasonic Wave Technology, Bronkhorst High-Tech BV (The Netherlands) added a new series to their family of liquid flow meters. Bronkhorst is a pioneer in the field of micro to low flow liquid metering instruments. In addition to their series of instruments based on the thermal measuring principle, the company introduced a unique series of low-flow mass flow meters and controllers based on the Coriolis measuring principle, providing high accuracy, fast response and fluid independence. The new ES-FLOW™ Ultrasonic Flow Meter was designed to measure tiny volume flows from 4 up to 1500 ml/min with high precision, high linearity and low pressure drop, using ultrasound in a small bore tube. Liquids can be measured independent of fluid density, temperature and viscosity. Thanks to the combination of a straight sensor tube with zero dead volume the flow meter is self-draining. The orbital TIG-welding allows hygienic connections...

Read more
The Flyweight That Packs a Heavyweight Punch

The Flyweight That Packs a Heavyweight Punch

FAULHABER has extended the extremely powerful BP4 product family with the brushless DC-Servomotor 2264...BP4. As well as having an outstanding ratio of torque to size and weight, the miniature drive comes with integrated sensors and a wide speed range.

The 4-pole motor achieves a torque of 59 mNm with a weight of just 140 g and a diameter of 22 mm. Furthermore, the 2264...BP4 reaches up to 34,500 revolutions per minute. The reason for the outstanding performance is the innovative segment winding of the coil, which was developed for the brushless DC-Motors of the BP4 family. Thanks to the overlapping, nested, individually wound segments, an especially large amount of copper can be accommodated in the coil. The high winding symmetry with minimal losses and appropriately high efficiency is a desirable side effect.

There is also room for a resilient shaft with a diameter of 4 mm and suitable bearings thanks to the compact coil. With its low inertia, the motor is well suited...
