Variable force spring and variable torque spring are very similar with constant force spring and constant torque spring. But we diversify the radian by winding the steel strip into a coil. Therefore, it can unfold negative gradient, positive gradient compounded in a spring. Here are some relations between load (force or torque) and stroke that can be used on specific occasion.
Pen Type Drug Injector Application
The spring exerts constant force to keep the drug flow fixed, preventing the patient from feeling uncomfortable when applying it. It features stretch force in end...
The Micro-Epsilon eddyNCDT 3060 inductive measurement system is based on eddy currents and enables fast, precise displacement measurements in industrial environments. Based on ease of use and smart signal processing, this non-contact system defines a new performance class in inductive displacement measurement. More than 400 sensor models can be combined with the eddyNCDT 3060.
In contrast to conventional inductive sensors, displacement sensors based on eddy currents stand out due to their high accuracy, bandwidth and temperature stability. Furthermore, this measuring...
FLIR A400/A700 Series thermal image streaming cameras offer the monitoring capabilities needed to accurately detect and identify thermal issues across manufacturing and industrial processes.
With multiple field-of-view choices, multi-streaming capabilities, motorized focus control, and optional compressed radiometric streaming over Wi-Fi, these fixed-mount camera solutions can tackle the most complex remote monitoring objectives.
Easy configuration allows you to tailor this monitoring system to your company’s quality, productivity, maintenance, and safety needs.
Measurement Computing adds a new member to its series of DAQ HATs - professional DAQ modules designed for the Raspberry Pi® platform. MCC 172 is a dual-channel module for acquiring IEPE sensor data.
MCC 172 accepts direct connection of piezoelectric sound & vibration sensors according to the popular IEPE standard. Data can be sampled simultaneously with 24-bit resolution and sampling rates up to 51.2 kS/s per channel. No additional signal conditioning will be required for acquiring aliasing-free signals up to 23 kHz. For higher channel count multiple DAQ HATs...
The FLIR A6750 SLS longwave camera is the ideal choice for high-speed thermal events and fast-moving targets. It offers extremely short integration times and windowed frame rates above 4,000 Hz, so you can freeze motion or achieve accurate temperature measurements on moving subjects.
The 640 x 512-pixel IR resolution and high sensitivity produce crisp imagery, well suited to electronics inspections, scientific research, and more.
For further information click here
The Microprecision MP600 mechanical position sensors offer superior accuracy, easy integration and high reliability - Quality made in Switzerland!
2 switching contacts, 1 NC and 1 optional NO, in a robust, cylindrical, pre-wired sensor housing.
The micron-calibrated distance between NC and NO is customer-defined, anywhere between 0.3 and 1.5mm.
Housing: M8, M12 or custom Actuators: Pin, ball, telescopic Sealing: IP67 Temperature: -40 to +130°C Hysteresis: 0 mm Repeatability: <...
The new WebDAQ 904 is a stand-alone universal input data logger designed for remote monitoring and control. All the intelligence is built into the WebDAQ, eliminating the need for a PC or additional software. WebDAQ 904 features four 24-bit simultaneously sampled analog input channels, individually configurable for voltage (up to ±60V), current, RTD, thermocouples, resistance, and bridge-based sensors.
Data can be recorded to the 3GB of internal storage, to external USB media or SD cards for virtually unlimited storage. By using the embedded WebDAQ web server, users can...
The high-performance FLIR RS8500 thermal camera combines a mid-wave infrared detector and telescope in a single weatherproof housing built for measurement accuracy of long-range and high-temperature targets in harsh environments.
The RS8500 allows for superior measurement accuracy through a MWIR detector, which provides high-definition, large-format thermal images with the ability to deliver data up to 180 frames per second, coupled with a high-resolution, 120-1200-millimeter continuous metric zoom lens.
This new MWIR thermal camera provides the ability...
The newly released Novodiag System allowing for rapid detection of the SARS-CoV-2 virus, responsible for coronavirus infection, is using Haydon linear technology.
“Despite searches, I could not find a market alternative which was able to meet the full criteria”.
Keep Reading the interview with Regis Melizzi, Instrument Team Manager at Mobidiag.
Click here to download PDF version
The miniaturized sensing heads are especially developed for the use in small and cramped surroundings and are perfect for applications with limited space, such as midgets instruments and engine constructions. The very advantageous cost-performance-ratio supports the integration of the pyrometers within OEM solutions and simultaneous use of the measurement devices at multiple infrared measuring facilities.
The compact series devices offer inimitable advantages for the installation in applications with high surrounding temperatures, such as within the plastic or paper industry. The...
