Smiths Interconnect’s modular and minimodular connectors are easy to assemble, based on the principle of building blocks with a system composed of two elements: modules and frames. Modules of various styles and different contact types are available for different application requirements, combining signal, power, coaxial, pneumatic and, from now on, data contact technologies into custom arrangements within a single connector frame.
Mark Kelleher, Connectors BU Director at Smiths Interconnect, said: “Our new Cat5e and Cat6A data transmission modules in accordance to IEEE 802.3 combine the proven technical characteristics of the hyperboloid contact with the use of high-quality and compliant insulator material - i.e. the polycarbonate family - to offer industry compliance and high performance”.
The electrical performance of these modules is optimized through low insertion loss, controlled impedance, and high return loss characteristics. These factors contribute to efficient signal transmission with minimal attenuation and reflection, reducing data errors and ensuring high-speed communication. Additionally, the use of high-quality conductors and advanced shielding techniques enhances resistance to electromagnetic interference (EMI), further stabilizing data transmission. By offering a high insulation resistance and low dielectric constant, the material supports consistent signal propagation and prevents unwanted capacitance effects. Moreover, its thermal and mechanical stability ensures long-term reliability, even in demanding environmental conditions.
Reliable performance in harsh conditions
Compared to existing commercial solutions, Smiths Interconnect Cat5e and Cat6A data transmission modules surpass various limitations, particularly in terms of operating temperature range and durability over multiple mating cycles. They are designed to withstand higher temperatures of up to +125°C and lower temperatures of -55°C, ensuring reliable performance in harsh environments where standard commercial solutions may fail due to material degradation, signal instability, or mechanical stress. This makes them ideal for applications in aerospace, defense, industrial automation, and other demanding sectors requiring consistent performance under varying environmental conditions.
Additionally, they are engineered for an extended number of mating cycles (up to 100,000), utilizing high-quality contact materials and advanced surface treatments that resist wear, oxidation, and contact degradation. This enhanced durability ensures stable electrical performance even after repeated connections and disconnections, thereby reducing maintenance requirements and extending the overall lifespan of the product.
Both new solutions can be used in the standard versions of the modular and minimodular series as well as in those compliant with EN45545 requirements for fire safety, and offer the following distinctive technical features and benefits:
- Hyperboloid contact technology utilizing high-quality contact materials and advanced surface treatments that resist wear, oxidation, and contact degradation. This enhanced durability ensures stable electrical performance over repeated connections and disconnections.
- 100,000 mating cycles as a connector: the extended life of the connector in applications like test and measurement, guarantees reduced maintenance costs through spares resulting in higher MTBF (mean time before failure).
- High-quality insulator material: This material plays a crucial role in maintaining dielectric properties, reducing signal degradation, and ensuring minimal crosstalk between conductors. This results in reliable performance through consistent signal propagation and unwanted capacitance effects. Furthermore, users benefit from long-term reliability through thermal and mechanical stability, even in demanding environmental conditions.
- Snap-in contacts: quick installation with simple assembly steps, requiring no special tools for all mounting arrangements e.g. panel, float for blind mating. This results in reduced operator's time to assemble parts and increased productivity.
As a result, Smiths Interconnect Cat5e and Cat6A modules offer significantly greater robustness and longevity compared to other solutions available in the marketplace, providing a reliable, cost-effective, and future-proof data transmission solution.
Finally, in parallel with the introduction of the new Cat5e and Cat6A modules, Smiths Interconnect proudly launches the new online configurator for the fully integrated modular L series.
