Miniature Circuit Breakers

The TA35 series from Schurter is a versatile generation of miniature circuit breakers with a UL rating of 277 VAC. The devices are engineered in a compact and attractive design and are available in 1-, 2- or 3- pole versions. The series offers both the function of ON/OFF switch and thermal overcurrent protection, with graduated rated currents available from 0.05 A to 20 A for 1-pole and 2-pole circuit breakers, and 0.05 A to 12 A for 3-pole circuit breakers.

Configurable rocker colors, lettering and illumination

The switch is highly configurable as it can be supplied with or without illumination in six colors, with standard print legends or customer-specific symbols. The circuit breakers are designed for snap-in mounting in panel thicknesses from 1 to 4 mm and the terminals are quick-connect 6.3 x 0.8 mm. In addition, the switch can also be exposed to dust and splashing water with the optional protective cover (IP 65 degree of protection).
