CO2 Probe
CO2 Probe

The digital EE871 probe from E+E Elektronik  measures CO2 concentration up to 50,000 ppm (5 % CO2). The compact probe is now available with a special filter cap, which ensures high accuracy and long-term stability in H2O2 contaminated environment. This opens up new applications for the EE871, particularly in the pharmaceutical and biotech industries, where hydrogen peroxide is used for cleaning and sterilization purposes.

CO2 infrared measuring principle

The CO2 infrared measuring principle (NDIR dual-wavelength technology) of the EE871 is inherently insensitive to contamination. The auto-calibration compensates for ageing effects and provides excellent long-term stability. Thanks to the multi-point CO2 and temperature adjustment, the EE871 offers a high measuring accuracy over the entire temperature range from -40 °C to 60 °C (-40...140 °F).

Configuration and adjustment

The measured values are optionally available on the Modbus RTU interface (up to 10,000 ppm) or the E2 interface (up to 50,000 ppm). Configuration and adjustment of the probe can be performed comfortably with the optional adapter kit.

Posted on January 25, 2018 - (2893 views)
E+E Elektronik Ges.m.b.H.
Langwiesen 7
4209 Engerwitzdorf - Austria
+43-7235-6050
+43-7235-6058
View full company profile
Description

E+E Elektronik develops and manufactures sensors and transmitters for humidity, temperature, dew point, moisture in oil, air velocity, flow, CO2 and pressure. Data loggers, hand-held measuring devices and calibration systems complete the comprehensive product portfolio of the Austrian sensor specialist. The main applications for E+E products lie in HVAC, building automation, industrial process control and the automotive industry. A certified quality management system according to ISO 9001 and IATF 16949 ensures the highest quality standards. E+E Elektronik has a worldwide dealership network and representative offices in Germany, France, Italy, Korea, China and the United States. The accredited E+E calibration laboratory has been commissioned by the Austrian Federal Office for Metrology (BEV) to provide the national standards for humidity and air velocity.
