Modular CO2 Transmitter

  Enquiry / contact me

For demanding OEM applications

Sensor Technology

Modular CO2 Transmitter
Modular CO2 Transmitter

The modular CO2 transmitter EE870 from E+E Elektronik is designed for maintenance-free use in demanding OEM applications. It offers various analogue outputs, Modbus interface, and a wide range of AC and DC supply voltage ranges. The compact, interchangeable probe measures CO2 concentrations up to 10,000 ppm and can be replaced within seconds without the need of calibration or adjustment. The user can change the measuring range of the transmitter by plugging in another probe. The probe is based on infrared technology (NDIR) and uses a dual wavelength auto-calibration procedure. Thus, it is completely maintenance free and highly resistant to environmental influences. Thanks to the factory multipoint CO2 and temperature adjustment, temperature compensation ensures excellent measurement accuracy over the entire operating range of -40... 60°C. Due to the probe's very high resistance to pollution, the device is particularly suitable for use in harsh conditions, such as greenhouses, stables, fruit and vegetable storage facilities, hatchers and incubators.

Posted on February 5, 2014 - (1055 views)
by
E+E Elektronik Ges.m.b.H.
Langwiesen 7
4209 Engerwitzdorf - Austria
+43-7235-6050
+43-7235-6058
View full company profile
Description

E+E Elektronik develops and manufactures sensors and transmitters for humidity, temperature, dew point, moisture in oil, air velocity, flow, CO2 and pressure. Data loggers, hand-held measuring devices and calibration systems complete the comprehensive product portfolio of the Austrian sensor specialist. The main applications for E+E products lie in HVAC, building automation, industrial process control and the automotive industry. A certified quality management system according to ISO 9001 and IATF 16949 ensures the highest quality standards. E+E Elektronik has a worldwide dealership network and representative offices in Germany, France, Italy, Korea, China and the United States. The accredited E+E calibration laboratory has been commissioned by the Austrian Federal Office for Metrology (BEV) to provide the national standards for humidity and air velocity.
