High Reliability Output Modules Ideal for Industrial Applications

Vox Power released two 300W output modules for use with their NEVO+600 and NEVO+1200 series modular power supplies

  • May 26, 2021
  • 276 views
  • High Reliability Output Modules Ideal for Industrial Applications
    High Reliability Output Modules Ideal for Industrial Applications
  • High Reliability Output Modules Ideal for Industrial Applications
    High Reliability Output Modules Ideal for Industrial Applications
  • High Reliability Output Modules Ideal for Industrial Applications
    High Reliability Output Modules Ideal for Industrial Applications
  • High Reliability Output Modules Ideal for Industrial Applications
    High Reliability Output Modules Ideal for Industrial Applications

Vox Power’s OPA2 and OPA3 modules provide field configurable, manually adjustable output voltages from 4.5 to 15V at 25A and 9 to 30V at 15A, respectively. With those output modules, NEVO+600 units only use two isolated, configurable power modules to achieve up to 600W while the larger 1200W model use up to four, thus reducing cable and link requirements and part count simplifying construction while increasing reliability (1 FPMH at 40⁰C at 80% load).

NEVO+ modular supplies smallest in class

The larger unit measures just 152.4 x 152.4 x 40.8mm (6 x 6 x 1.61in) resulting in a power density figure of 21W/in³. With only 1,2kg, the NEVO+1200 includes 90% efficiency, a standby power of less than 3W, accurate current sharing and the capacity to connect modules in parallel and series. NEVO+ units can be configured in the field and current and voltage programming can be done remotely. They also comply with IEC/UL60950-1 2nd Ed, IEC/UL62368-1 2nd Ed, IEC61000 and IEC55011 for EMC requirements and is CE/UKCA marked.
